400/60-15.5 16L 145A8 FTB190 ASCENSO / 13.00X15.5 F6 161X205X21.5(A2) ET0

PRIMER EQUIPO

Product sheet

Information

Code	PE6085

Dimension and weight

Dimension	40060155

*Technical data are for information purposes only, may be subject to modifications by the manufacturer and are valid except in the case of typographical errors.

400/60-15,5 16L FTB190 TL 148A8/144B

ASCENSO

Product sheet

Information

Code	AS2720
EAN	8904365501016
Model	FTB190
Ply/Ply Rating	16
Product type	Agriculture
Construction	Cross Ply
TT/TL	TL
Recommended rim	AG13.00
Pressure* (bar)*	3.60
Retreaded	NO

Load Index/ Speed Code

Load Index	148/144
Speed Rating	A8/B
Load capacity 1 (kg)	3150
Load capacity 2 (kg)	2800
Recommended load at 25km/h (kg)	3450
Recommended load at 40km/h (kg)	2900
Speed (km/h)	40
Speed 2(km/h)	50

Dimension and weight

Dimension	40060155
Width (mm)	404.00
Diameter (mm)	874.00
Rolling circumference (mm)	2625.00
Weight (kg)	34.02
Radio bajo carga (mm)	395.00

*Technical data are for information purposes only, may be subject to modifications by the manufacturer and are valid except in the case of typographical errors.

*The inflation pressure is always determined according to the load per tyre, the speed and the work to be performed. The following recommendations are given subject to subsequent modifications.
